Adhesive-Bonded Bentonite GCL (AH)

What is Geosynthetic Clay Liner (GCL)?

HX^® Bentonite Geosynthetic Clay Liner(GCL) is a new type of geosynthetic material. It is a blanket-like waterproof membrane made of graded natural sodium bentonite particles and corresponding additives mixed as raw materials. The bentonite particles are fixed between geotextiles and plastic woven fabrics through a needle punching process. Bentonite waterproof blanket not only has all the characteristics of geotechnical materials, but also has excellent waterproof (seepage) performance.

GCL-AH series is a needlepunched, thermally reinforced composite comprised of a core of natural sodium bentonite clay between two durable geotextile layers to form a low permeability hydraulic barrier. The top layer is a staple fiber nonwoven geotextile while the bottom layer is a woven geotextile. The bottom woven geotextile contains a rugged adhesive geofilm to provide a geomembrane type of hydraulic conductivity. The product is intended for applications that require excellent hydraulic conductivity properties.

Specification:

Width: 1m-6m or follow customers' demand
Length: Normal 30m, can as per your request
Color: Black, white or as customers' required

What are the different types of GCL?

There are several different types of Geosynthetic Clay Liners (GCLs), each designed to meet specific project requirements and environmental conditions. The main types of GCLs include:

Sodium Bentonite GCL: This is the most common type of GCL and consists of a layer of natural sodium bentonite clay sandwiched between two geotextile layers. When hydrated, the bentonite clay swells to create an impermeable barrier, effectively sealing against water and contaminants.

Calcium Bentonite GCL: Similar to sodium bentonite GCL, calcium bentonite GCL utilizes calcium bentonite clay instead of sodium bentonite. It offers similar sealing properties and is often used in applications where sodium is not desired due to its potential impact on certain environments.

Polymer-Modified GCL: In this type, the natural bentonite clay is mixed with a polymer additive. This modification enhances the clay’s properties, such as its swell capacity and resistance to certain chemicals, making it suitable for more challenging conditions.

Geotextile-Encased GCL: Instead of two geotextile layers, this type incorporates a single geotextile layer on one side, while the other side is left exposed as the clay barrier. It offers flexibility in design and can be used in applications where a single-sided liner is sufficient.

Geocomposite GCL: Geocomposite GCLs combine the sealing properties of bentonite clay with other geosynthetic materials, such as geomembranes or geotextiles. This type offers enhanced performance in terms of chemical resistance, puncture resistance, and durability.

Adhesive-Bonded GCL: In adhesive-bonded GCLs, the bentonite clay layer is adhered to a geotextile using a specialized adhesive, creating a robust barrier against fluid migration.

Sprayed GCL: This type involves applying a layer of bentonite slurry directly onto a geotextile. It offers an alternative method of constructing a clay barrier.

Each type of GCL has its own advantages and considerations, and the choice depends on factors such as the project’s specific requirements, environmental conditions, and desired performance characteristics.

What are Geosynthetic Clay Liners (GCLs) used for?

HX^® Geosynthetic Clay Liners (GCLs) are used for a variety of engineering and environmental applications that require containment, fluid control, and hydraulic barriers. Some of the common uses of GCLs include:

Landfill Liners and Caps: GCLs are employed as liners and caps in landfill systems to prevent the migration of leachate (liquids generated by waste decomposition) into the surrounding soil and groundwater. They help protect the environment from contamination.
Waste Containment: GCLs are used in waste containment facilities, such as hazardous waste storage areas, to prevent the release of harmful chemicals into the environment.
Wastewater Treatment: GCLs are utilized in wastewater treatment plants to line ponds, lagoons, and other structures, preventing the seepage of treated or untreated wastewater into the ground.
Pond and Canal Liners: GCLs are used as liners for ponds, canals, and reservoirs to prevent water seepage, control water levels, and protect surrounding areas from erosion.
Mining and Tailings Management: GCLs are applied in mining operations to line tailings ponds, preventing the leaching of toxic substances into the environment.
Environmental Remediation: GCLs are used in projects aimed at remediating contaminated sites, preventing the spread of pollutants and protecting the surrounding ecosystem.
Infrastructure Projects: GCLs find use in infrastructure projects like road construction, tunneling, and underground structures, providing waterproofing and erosion control.
Erosion Control: GCLs are used to stabilize slopes, embankments, and shorelines, preventing soil erosion and ensuring structural stability.
Secondary Containment: GCLs are employed as secondary containment systems for tanks, pipelines, and other facilities to prevent the leakage of hazardous materials.
Waterproofing: GCLs are used for waterproofing applications in various civil engineering projects, such as retaining walls and building foundations.
The versatility, cost-effectiveness, and environmental benefits of GCLs make them a valuable solution for addressing various containment and hydraulic control challenges across different industries and projects.

Performance

HX^® Geosynthetic Clay Liners (GCLs) are engineered to deliver exceptional performance and reliability in a wide range of containment and hydraulic control applications. With a focus on quality, durability, and environmental protection, our GCLs offer the following outstanding product performance:

Effective Hydraulic Barrier: HX^® GCLs incorporate high-quality bentonite clay that swells upon contact with water, forming an impermeable barrier. This hydraulic barrier prevents the migration of fluids, contaminants, and leachate, safeguarding the surrounding environment from pollution.

Enhanced Containment: Our GCLs provide superior containment solutions for landfills, waste storage facilities, and industrial sites. They effectively confine hazardous substances, preventing their release and minimizing the risk of environmental contamination.

Chemical Resistance: HX^® GCLs are designed to withstand a wide range of chemical exposures, ensuring their integrity and performance even in challenging environments with varying pH levels and chemical compositions.

Durability and Longevity: Engineered with robust geotextile layers, our GCLs exhibit exceptional strength and durability. They maintain their sealing and containment properties over time, providing long-lasting protection and minimizing maintenance requirements.

Easy Installation: The user-friendly design of HX^® GCLs simplifies installation processes, reducing project timelines and labor costs. This ensures efficient and hassle-free deployment, enhancing overall project efficiency.

Versatile Applications: Whether for landfill liners, pond liners, mining operations, or other containment projects, HX^® GCLs excel in a variety of applications, offering versatile solutions for diverse engineering and environmental challenges.

Sustainability: Our commitment to sustainability is reflected in the eco-friendly composition of HX^® GCLs. By preventing the migration of pollutants and contaminants, they contribute to the preservation of natural resources and ecosystems.

Compliance and Standards: HX^® GCLs meet stringent regulatory standards and industry guidelines for containment and environmental protection. They are engineered to deliver reliable performance that aligns with the highest quality and compliance requirements.

Expert Support: Backed by our team of geosynthetic experts, HX^® GCLs come with comprehensive technical support and guidance. Our team is available to assist with product selection, installation recommendations, and project-specific solutions.

HX^® Geosynthetic Clay Liners provide a proven and effective solution for a wide range of projects, offering superior performance, durability, and environmental responsibility.
